TE Connectivity 524-AG11D-ES 24-Pin DIP Socket

The TE Connectivity 524-AG11D-ES is a through-hole IC socket designed for 24-pin DIP packages with a 0.100″ (2.54 mm) pitch. It features high-reliability, four-finger gold-plated mating contacts and tin-lead posts, making it suitable for long-term use in serviceable boards. According to the datasheet, it supports up to 3 A current and has a contact resistance of about 10 mΩ. The housing is made of UL94 V-0 polyester, and the recommended operating temperature ranges from –55 °C to +105 °C. Request a quote for availability and price.
