BAV23-TR Compact General Purpose Double Diode

BAV23-TR is a general-purpose double diode in a compact surface-mount package. The device contains two unconnected diode elements in one package, giving engineers separate diode paths within a single component. Its planar construction is intended for general applications where the BAV23 electrical arrangement and package are specified. The surface-mount format keeps the connection points close together and suits automated assembly on printed circuit boards. Because the two diodes are independent internally, the circuit determines how each element is connected and used. Choose it when the schematic and footprint are designed for this four-terminal double-diode configuration. For service or replacement work, verify the terminal layout against the original board before installation. Request a quote for BAV23-TR.
