BAV70-7 Common Cathode Dual Diode

BAV70-7 is a dual surface-mount switching diode with a common-cathode configuration. It combines two diode elements in one three-terminal package, allowing both switching paths to share the same cathode connection. The device is intended for general-purpose switching and offers a compact way to implement this circuit arrangement on a printed circuit board. Its surface-mount package is suited to automated placement and layouts where board area is limited. The integrated structure keeps the common-cathode pair within one defined component footprint. Engineers should select it when the schematic calls for the BAV70 common-cathode topology and the correct package footprint. During repair work, check the terminal arrangement before replacing another diode array with a similar case. Request a quote for BAV70-7.
