BM04B-PASS-TFT(LF)(SN) Surface Mount Top Entry Header

BM04B-PASS-TFT(LF)(SN) is a four-contact top-entry header for surface-mount wire-to-board connections. The header has one row, a 2.0 mm terminal pitch, and a without-boss housing configuration. Copper-alloy posts with tin plating provide the electrical contacts. The base housing is heat-resistant polyamide, and the SMT construction also uses tin-plated copper-alloy reinforcement pieces. Its electrical rating is 3 A and 250 V AC/DC under the specified conditions. The top-entry form provides a straight mating direction above the PCB, while the solder terminals are intended for direct surface mounting. BM04B-PASS-TFT(LF)(SN) is part of a connector system that uses a matching wire housing and crimp contacts to complete the connection. Request a quote for BM04B-PASS-TFT(LF)(SN).
