75 V Zener Diode Packaged for Reel Feed Assembly

BZX84-C75TR sits at the top of its voltage regulator family, with a nominal working voltage of 75 V and a ±5% tolerance range. It ships in the SOT23 (TO-236AB) surface-mount package on tape and reel, which suits automated pick-and-place lines. Total power dissipation is capped at 250 mW at 25°C ambient, and the non-repetitive peak reverse power dissipation reaches up to 40 W across the family, though this specific voltage grade carries a lower peak current rating than the lower-voltage variants in the same series. Forward voltage stays at or below 0.9 V at 10 mA. Because of its higher working voltage, BZX84-C75TR fits applications needing overvoltage clamping or reference points well above typical logic-level rails. Request a quote for BZX84-C75TR
