C0603C223K4RAC9799 Compact 0.022 µF MLCC

C0603C223K4RAC9799 is a listed 0.022 µF X7R multilayer ceramic capacitor with ±10% tolerance and a 16 VDC rating. The 0603 package measures 1.6 mm by 0.8 mm, with a thickness of 0.8 mm ±0.07 mm. Its Class II dielectric is specified for operation from -55°C to +125°C and suits compact bypass or decoupling positions. The lower voltage rating can fit low-voltage rails when the design retains suitable margin. Account for capacitance shift caused by temperature, applied DC voltage, and aging when reviewing circuit performance. Compare the exact footprint, dielectric, capacitance, tolerance, and voltage requirements before assembly. Tin terminations support standard reflow soldering on properly prepared surface-mount boards. Request a quote for C0603C223K4RAC9799.
