C0603C224Z4VAC General Purpose 0.22 µF MLCC

C0603C224Z4VAC is a 0.22 µF Y5V multilayer ceramic capacitor with a 16 VDC rating and a -20% to +80% tolerance. The 0603 body measures 1.6 mm by 0.8 mm, with a specified thickness of 0.8 mm ±0.10 mm. Its general-purpose Class III dielectric operates from -30°C to +85°C and permits substantially more capacitance change than C0G or X7R types. Use it only where that broad tolerance and Y5V temperature behavior meet the circuit requirements. Effective capacitance should be assessed under the expected temperature and DC bias conditions. Confirm the footprint, voltage margin, and acceptable capacitance range before placement. Tin terminations allow standard surface-mount soldering on a correctly designed land pattern. Request a quote for C0603C224Z4VAC.
