ERJ-8GEYJ682V 6.8 kOhm 1206 Thick Film Chip Resistor

ERJ-8GEYJ682V is a stable choice for biasing and pull networks in automotive-grade electronics where a standard 1206 footprint is required. This thick film chip resistor is specified at 6.8 kOhms with ±5% tolerance and a 0.25 W (1/4 W) power rating. It carries an Automotive AEC-Q200 feature note, with a temperature coefficient of ±200 ppm/°C and an operating temperature range of -55°C to 155°C. The package is 1206 (3216 metric) with a 3.20 mm x 1.60 mm outline and 0.70 mm max seated height, using 2 terminations for reflow assembly. Request a quote for ERJ-8GEYJ682V.
