ES2B fast recovery rectifier diode with 100V Vr and 2A Io

ES2B is a single, standard rectifier diode designed around a fast recovery profile and supplied in a DO-214AA (SMB) surface-mount package. Electrical ratings include 100 V DC reverse voltage (Vr max) and 2 A average rectified current (Io). Maximum forward voltage is 900 mV at 2 A. Reverse recovery time (trr) is 20 ns, and speed class is fast recovery (≤ 500 ns, > 200 mA). Reverse leakage is 10 µA at 100 V. Capacitance is 18 pF at 4 V and 1 MHz. Operating junction temperature range is -55°C to 150°C. ES2B is typically grouped with compact rectifiers where recovery characteristics and low capacitance are selection drivers. Request a quote for ES2B.
