L101C104LF Supports Compact, Stable Resistor Network Designs

The L101C104LF is a 100K ohm resistor network from TT Electronics, built for circuit designs that need multiple resistors in a compact package. It uses a bussed circuit configuration with nine resistors and ten pins, making it a practical choice when board space and clean connections matter. The SIP-10 package supports through-hole mounting and measures 25.4 mm long, 2.41 mm wide, and 4.95 mm high. Its compact single-inline format can help simplify layouts where repeated resistance values are required across multiple circuit paths.

With a 2% tolerance and a 100 PPM/°C temperature coefficient, the L101C104LF offers consistent resistance across changing operating conditions. Each resistor is rated at 0.125 W, while the network carries a 100 V voltage rating. The part is also RoHS compliant, supporting applications with environmental requirements.

Need the L101C104LF for a repair, replacement, or new design? Contact Florida Circuit today to check availability and request a quote.
