SN74S09N NAND Gate: Open Collector, Fast TTL

SN74S09N is a Texas Instruments quad 2-input NAND gate built for shared-output logic designs. Each gate features an open-collector output, allowing multiple devices to connect on the same line when used with external pull-up resistors. SN74S09N uses Schottky TTL technology to deliver fast switching and controlled propagation delay. It operates from a standard 5 V supply and maintains stable logic levels under defined load conditions. Engineers rely on SN74S09N for clock control, signal gating, and wired-AND logic applications. The N package supports through-hole assembly and simplifies field replacement. Choose SN74S09N when output flexibility and timing matter. Order SN74S09N today from Florida Circuit.
